Electric Automatic 16×20 Double Side Station Heat Transfer Press Machine With Laser Alignment

  • Model NO.:

    B2-2N ProMax

  • Description:
  • Being powered by electric gear technology with 350 – 500kg heat pressing for heavy pressure application, which is world class level. With two heat printing stations, the 40 x 50cm Dual Manual Electric Pro Two Heat Press (SKU#: B2-2N Pro Max) increases efficiency by allowing threading and layout on one station while the other is working. It’s perfect for high-volume operations. It also offers heat-free workspace, touch screen settings, live digital time, temperature, and pressure readouts. Plus, with lower plates thread-ability, you can position a garment once, rotate and decorate any area.

    P.S. Please click instruction download as PDF and read more.

  • Style: Dual Plates Electric Heat Press
  • Features: Automatic | Electric
  • Platen Size: 40 x 50cm
  • Dimension: 94.7x82x71.7cm
  • Certificate: CE (EMC, LVD, RoHS)
  • Warranty: 12 Months
  • Contact: WhatsApp/Wechat: 0086 - 150 6088 0319
  • Description

    Product Tags


    Upgraded version with a moveable table and laser locator, Code#:FJXHB2-2N Pro Max, it is a full electronic heat press on the top line by bring a high effiencient when it comes to the mass production at high quality levels. This unit can handle anything – large or small garments, multiple ceramic tiles, and many  other substrates. It does not require compressed air, which makes it more convenient. It features high efficiency & excellent pressure, can operate in full-auto, or semi-auto modes. Its speed moving from left to right is adjustable. Full-range repeatable pressure adjustments for items up to 4.5cm thick, LCD screen controller, and live digital time, accurate temperature read-out and Max. 120min set automatic stand-by. (Table and Laser locator can sold seperately)

    Products Detail

    Double Station Heat Press Machine
    Electric Heat Press Machine
    Automatic T-shirt Heat Press
    Heat Press Machine
    Heat Press Machine for T-shirts
    Heat Press Machine Caddie
    Heat Press Quick Platens

    Additional features

    heat press

    Triple Thermal Production

    Two thermal protection decices connect separately with live wire and Neutral Wire, the third protection is heatong plate with temperature protector which prevent abnormal temperature rise.

    heat press

    Thread-able & Interchangeable Base

    This EasyTrans Press is installed with a featured base: 1. Quick changeable system enables you to change the different accessory platen in few seconds. 2. The thread-able base enables you to load or rotate the garment over the lower platen.

     heat press

    Advanced LCD Controller

    This heat press is also equipped with advanced LCD controller AT700 series, super precise in Temp control and read-out. User could set the applying pressure by controller setting (P-4 mode). The controller is also featured with Max. 120mins stand-by function (P-5 mode) make it energy saving and safety.


    Double Station

    The electric dual station heat press transitions from platen to platen, allowing you to thread and remove garments quickly and easily.

     heat press

    Pop-out Controller

    A pop-up controller makes instrument replacement easier.


    16X20 Platen

    There is enough size to print all kinds of products.

    heat press

    Protective Cap

    Protective Cap is safer and anti-scalding.

    heat press

    Four Support Springs

    Ensure balanced pressure ditribution

    double station heat press

    Accepts items up to 1.97" Thick

    Ensures sufficient thickness for major substrates


    Heat Press Style: Electric
    Motion Available: Swing-away/ Auto-open
    Heat Platen Size: 40x50cm
    Voltage: 110V or 220V
    Power: 1800-2200W

    Controller: Screen-touch LCD Panel
    Max. Temperature: 450°F/232°C
    Timer Range: 999 Sec.
    Machine Dimensions: 94.7 x 82 x 71.7cm
    Machine Weight: 125kg
    Shipping Dimensions: 110 x 83 x 87cm
    Shipping Weight: 140kg

    CE/RoHS compliant
    1 Year entire warranty
    Lifetime technical support
